8 Channel HD SDI To HDMI Video Converter+Rj45 20KM Support LC / PC Optical Connector

China 8 Channel HD SDI To HDMI Video Converter+Rj45 20KM Support LC / PC Optical Connector supplier

Large Image :  8 Channel HD SDI To HDMI Video Converter+Rj45 20KM Support LC / PC Optical Connector

Product Details:

Place of Origin: China
Brand Name: Ho-link
Certification: CE/ROHS/FCC/SGS
Model Number: HD-SDI

Payment & Shipping Terms:

Minimum Order Quantity: 1pair
Price: Negotiation
Packaging Details: International Standard Package
Delivery Time: Shipped within 3 working days after payment confirmed
Payment Terms: T/T, Western Union
Supply Ability: 6000pairs+one month
Contact Now
Detailed Product Description
Color: Black Type: HD-SDI
Channels: 1/2/4/8 Channels Video: BNC 75Ω
Single-mode: 20Km – 80Km Wavelength- Mulitmode: 850/1310nm


SD-SDI/HD-SDI/3G-SDI Video Over Fiber Converter



System Design
Fiber Optic Video Transmitter & Receiver:

  SDI series can transmission 1/2/4/8-Channels
  SD-SDI/HD-SDI/3G-SDI video over 1 single core fiber.8 Channel HD SDI To HDMI Video Converter+Rj45 20KM Support LC / PC Optical Connector
8 Channel HD SDI To HDMI Video Converter+Rj45 20KM Support LC / PC Optical Connector


Single-Mode or Multi-Mode:
  SD-SDI/HD-SDI/3G-SDI units are designed to support LC /PC Optical connector
  We will offer free patch cord + adaptor for your request for SC/PC or ST/PC or FC/PC optical connector.
  The Transmission distance Range according to the Optical Budget.
  Manufacturer's default standard is single mode 20Km .



Features:
•   1/2/4/8 Channels Video of SD-SDI/HD-SDI/3G-SDI can be transmitted via 1 single fiber
•   The Max rate of work is 3.2Gb/s
•   Support SMPTE 292M (2.9Gb/s) clock recovery
•   Support standard of 1.485Gbps/M(HD-SDI/ SD-SDI),SMPTE 425M 3Gb/s Mapping(3G-SDI),SMPTE 424M 3Gb/s serial interface(3G-SDI)
•   Out wavelength range is 1310nm,1550nm and 16 other kind of CWDM wavelength ( comply with ITU-T G.694.2)
•   Automatic cable equalization, used for all rate below 3.2 Gb/s(Belden 1694A)
•   LED Status Indication to monitor the working conditions
•   Video transmission system can support many application branches structure
•  The fiber port Support SFP transceiver hot-plugged
•  The SDI video format support:
   625/25 PAL
   525/29.97 NTSC
   525/23.98 NTSC
   720p50, 720p59.94
   1080P 23.98/24/30/50/60
   1080i 23/24/30/50/59.94




Typical application:
8 Channel HD SDI To HDMI Video Converter+Rj45 20KM Support LC / PC Optical Connector


8 Channel HD SDI To HDMI Video Converter+Rj45 20KM Support LC / PC Optical Connector
Remark:

•  The Optical Power Budget fit Multi-mode(62.5/125μm),Single-Mode(9/125μm).
•  When using 50/125μm multimode fiber, subtract 3dB from the optical power budget.
•  Optical transmission distance is limited to optical loss of the fiber and any additional loss introduced by connectors, splices and patch panels.
•  Maximum transmission distance is also limited by fiber bandwidth.
•  Power adapter for stand-alone units is manufactured by third party. Power adapter included US, European, UK or Australian power plug.
•  Please feel free to contact factory for any special requirement and customization




Specifications:


Parameter Description
Video connector BNC
The interface bandwidth 1.4835Gbps,1.485Gbps,2.97Gbps
impedance 75Ω
Resolution

1920*1080@60Hz; 1920*1080@50Hz; 1920*1080@30Hz; 1920*1080@25Hz; 1920*1080@24Hz; 1280*720@60Hz;
1280*720P@50Hz; 525i; 625i

RS485 connector Industrial terminals
Baud rate Self-adaptive, Max:115200bps
Optical fiber Self-adaptive, Max:115200bps LC/SC
Wavelength Single-mode 1310nm
Transmission distance Single-mode:3/20/40/80km
Other Power Power adapter:DC 5V/2A
Power dissipation MAX 2.5W
Size 120mmX97.5mmX25.2mm



Environmental:

*  Operating Temperature : -45 C~+75 C
*  Storage Temperature : -45 C~+85 C
*  Relative Humidity : 0%~95% (non-condensing)
*  MTBF : >100,000 hours

Remark: To meet the needs of our customers and help them to realize their projects, we also can manufacture the products according to customers' requirements.
