1 Channel HDMI to Fiber Converter with Audio & RS232 to Fiber Converter Support KVM

China 1 Channel HDMI to Fiber Converter with Audio & RS232 to Fiber Converter Support KVM supplier
1 Channel HDMI to Fiber Converter with Audio & RS232 to Fiber Converter Support KVM supplier 1 Channel HDMI to Fiber Converter with Audio & RS232 to Fiber Converter Support KVM supplier 1 Channel HDMI to Fiber Converter with Audio & RS232 to Fiber Converter Support KVM supplier 1 Channel HDMI to Fiber Converter with Audio & RS232 to Fiber Converter Support KVM supplier 1 Channel HDMI to Fiber Converter with Audio & RS232 to Fiber Converter Support KVM supplier

Large Image :  1 Channel HDMI to Fiber Converter with Audio & RS232 to Fiber Converter Support KVM

Product Details:

Place of Origin: China
Brand Name: Ho-Link/OEM
Certification: CE/FCC/ROHS
Model Number: H-HDMI-1V1D1A-T/RL

Payment & Shipping Terms:

Minimum Order Quantity: 1 Pair
Price: Negotiable
Packaging Details: International Standard Package
Delivery Time: 3 working days after received your payment
Payment Terms: T/T or western Union
Supply Ability: 3,000pair per month
Contact Now
Detailed Product Description
Product Name: HDMI Over Fiber Converte Application: Multimedia Publishing System
Product Status: Stock Max Resolution: 1920*1080
Color: Black I/O: VGA/DVI/HDMI

HDMI Video & Audio & RS232 to Fiber Converter for Advertising ,Support 1080P@30Hz/60Hz,3G Fiber Bandwidth



Overview:

     H-HDMI-1V1D1A-T/RL VGA/DVI/HDMI extender is designed specially for the projects that require transmitting high definition signals to remote location . The product includes a transmitter and a receiver, which can extend video, audio, RS232,USB and MIC interfaces of computer max up to 2km/20km over SM/MM fiber cable, so that users can see the picture image and hear the voice of computer remotely.

They are widely used in military command and control system, police command and control system, traffic management system, energy and electricity supply industry, government office, medical system, commercial presentation, multimedia and public utilities etc.

1 Channel HDMI to Fiber Converter with Audio & RS232 to Fiber Converter Support KVM



Specifications:


Video I/O connector VGA/DVI/HDMI
HDMI version HDMI1.1 1.2 1.3
HDCP HDCP1.2
HDMI resolution 1080p/1080i/720p/720i/576p/576i/480p/480i
Video color format 24bit/deep color 30bit/deep color 36bit
Audio format DTS/HD/Dolby-tureHD/LPCM7.1/DTS/Dolby-AC3/DSD
TMDS 0.5-1.5Vp-p(TTL)
DDC 5Vp-p(TTL)
Input cable length ≤20m AWG26 HDMI 1.3 standard cable
Output cable length ≤20m AWG26 HDMI 1.3 standard cable
USB Protocol Support USB2.0 protocol
Audio Connector USB-to-3.5mm audio Jack
Optical Connector SM/MM SC/FC type
Wave length 850nm/1310nm/1550nm
Physical Size (L× W ×H) Sender : 164mm*115mm*26mm Receiver: 164mm*123mm*26mm
Case metal
Color Black
N.W. 0.75Kg
Power Voltage 5V DC
Power consumption 15W
Environment Working temperature -15℃-55℃
Storage temperature -40-80℃
Humidity 0-95% (non-condensing)









Each LED indicator lamp:



Indicator Light HDMI Transmitter HDMI Receiver
VIDEO On Video signal on
Off Video signal off
LOCK On Fixed video signal
Off Not fixed video signal
RUN On Device works smoothly
Off Device not works smoothly
POWER On Power on
Off Power off








Main Features:

1, Support KVM

2, The attenuation of optical module SFP low to -3db

3, Automatic equalization inside, stable and clear graphics.

4, Full digital, Uncompressed HD optical fiber transmission

5, Support HDMI 1.3b Protocal

6,Transmit 1-ch HDMI video & 1-ch stereo audio & 1-CH RS232 DATA over one fiber







Applications:

1 Channel HDMI to Fiber Converter with Audio & RS232 to Fiber Converter Support KVM









Packaging & Shipping



1 All of our package are international standard package

2 We will deliver our products as soon as the order confirmed

1 Channel HDMI to Fiber Converter with Audio & RS232 to Fiber Converter Support KVM





Payment



1 Channel HDMI to Fiber Converter with Audio & RS232 to Fiber Converter Support KVM



Our Services



Welcome to inquire!



1 Channel HDMI to Fiber Converter with Audio & RS232 to Fiber Converter Support KVM
