Industrial Hd Sdi To Fiber Optic Converter Catv Fiber Optic Transmitter Receiver

China Industrial Hd Sdi To Fiber Optic Converter Catv Fiber Optic Transmitter Receiver supplier
Industrial Hd Sdi To Fiber Optic Converter Catv Fiber Optic Transmitter Receiver supplier Industrial Hd Sdi To Fiber Optic Converter Catv Fiber Optic Transmitter Receiver supplier Industrial Hd Sdi To Fiber Optic Converter Catv Fiber Optic Transmitter Receiver supplier Industrial Hd Sdi To Fiber Optic Converter Catv Fiber Optic Transmitter Receiver supplier

Large Image :  Industrial Hd Sdi To Fiber Optic Converter Catv Fiber Optic Transmitter Receiver

Product Details:

Place of Origin: China
Brand Name: Ho-link/OEM
Certification: CE/ROHS/FCC
Model Number: HL-1V-20T/R/HD-SDI

Payment & Shipping Terms:

Minimum Order Quantity: 1 Pair
Price: Negotiable
Packaging Details: Neutral /Standard/Customized packing
Delivery Time: 3 working days after received your payment
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 10000pcs/month
Contact Now
Detailed Product Description
Product Name: HD-SDI To Fiber Converter Connector: Industrial Terminals
Power: Power Adapter:DC 5V/2A Reflection Loss: >15DB
Size: 120mmX97.5mmX25.2mm Operating Temperature Range: -5℃ ~ +70℃



hd-sdi fiber optical transmitter and receiver,data transmitter and receiver/catv fiber optic transmitter receiver







Product Description



* 4 Channel Digital CCTV hd-sdi video transmitter Advantages



1. Manufacturer, factory price
2. In stock, fast shipping
3. CE/FCC/RoHs
4. OEM ODM service



* 4 Channel Digital CCTV hd-sdi video transmitter Features



1. 8-bit or 10-bit digitally encoded and non-compression video transmission

2. Directly compatible with NTSC, PAL and SECAM CCTV camera systems and support RS-232, RS-422 and RS-482 data protocols

3. Power supply and other parameter state indication, which can monitor the operation condition of system

4. Support no-damage regenerative trunk of video

5. Constant input optical power, and large dynamic range, no electrical or optical adjustments required

6. Special ASIC design

7. Industry-grade of operating temperature from 10 to 75, which is applied to the different working environment

8. Hot-swap function

9. Stand-alone type or card-type installed in 19" 2U or 4U rack-mount chassis

10. Optical interface: FC, ST, SC(optional)

11. Abundant signal interface, such as video, data, audio, telephone, Ethernet, binary input/ output and talkback

Features



•1/2/4/8 Channels Video of SD-SDI/HD-SDI/3G-SDI can be transmitted via 1 single fiber

The Max rate of work is 3.2Gb/s

Support SMPTE 292M (2.9Gb/s) clock recovery

• Support standard of 1.485Gbps/M(HD-SDI/ SD-SDI),SMPTE 425M 3Gb/s Mapping(3G-SDI),SMPTE 424M 3Gb/s serial interface(3G-SDI)

• Out wavelength range is 1310nm,1550nm and 16 other kind of CWDM wavelength ( comply with ITU-T G.694.2)

• Automatic cable equalization ,used for all rate below 3.2 Gb/s(Belden 1694A)

LED Status Indication to monitor the working conditions

Video transmission system can support many application branches structure

•The fiber port Support SFP transceiver hot-plugged

The SDI video format support:

625/25 PAL

525/29.97 NTSC

525/23.98 NTSC

720p50,720p59.94

1080P 23.98/24/30/50/60

1080i 23/24/30/50/59.94

Typical application

Industrial Hd Sdi To Fiber Optic Converter Catv Fiber Optic Transmitter Receiver



Industrial Hd Sdi To Fiber Optic Converter Catv Fiber Optic Transmitter Receiver



Remark



•The Optical Power Budget fit Multi-mode(62.5/125m),Single-Mode(9/125 m).

•When using 50/125 m multimode fiber, subtract 3 dB from the optical power budget.

•Optical transmission distance is limited to optical loss of the fiber and any additional loss introduced by connectors, splices and patch panels.

•Maximum transmission distance is also limited by fiber bandwidth.

•Power adapter for stand-alone units is manufactured by third party .Power adapter included US, European, UK or Australian power plug.

•Please feel free to contact factory for any special requirement and customization



Specifications





Parameter Description
Video connector BNC
The interface bandwidth 1.4835Gbps,1.485Gbps,2.97Gbps
impedance 75Ω
Resolution

1920*1080@60Hz; 1920*1080@50Hz; 1920*1080@30Hz; 1920*1080@25Hz; 1920*1080@24Hz; 1280*720@60Hz;

1280*720P@50Hz; 525i; 625i

RS485 connector Industrial terminals
Baud rate Self-adaptive, Max:115200bps
Optical fiber Self-adaptive, Max:115200bps LC/SC
Wavelength Single-mode 1310nm
Transmission distance Single-mode:3/20/40/80km
Other Power Power adapter:DC 5V/2A
Power dissipation MAX 2.5W
Size 120mmX97.5mmX25.2mm
