DC 5V 2A HD 1080p Video Converter 8-Ch HDCVI / HDTVI / AHD Video Converter

China DC 5V 2A HD 1080p Video Converter 8-Ch HDCVI / HDTVI / AHD Video Converter supplier

Large Image :  DC 5V 2A HD 1080p Video Converter 8-Ch HDCVI / HDTVI / AHD Video Converter

Product Details:

Place of Origin: CHINA
Brand Name: HOLINK
Certification: CE RoHS
Model Number: H-CVI/TVI/AHD-4V-T/RF

Payment & Shipping Terms:

Minimum Order Quantity: 1PAIRS
Price: USD 1-160 1 PAIR
Packaging Details: international standard package
Delivery Time: 2-3 workdays
Supply Ability: 10000PAIRS ONE MONTH
Contact Now
Detailed Product Description
Number Of Channels: 1~16 Fiber: Single Mode Single Fiber
Sampling Bandwidth: 10bit Power: DC5V 2A
Power Consumption: ≤7W Corlor: Black

720P/960P/1080P HDCVI Camera Fiber Video Converter,8-Ch HDCVI/HDTVI/AHD Video Converter



Product Description



Introduction



HD CVI /AHD /TVI video converter is designed for long-distance optical fiber transmission.

It adopt the advanced uncompressed HD composite video and high velocity digital optical

transmission technologies which convert the high definition signals to optical signals.



HD CVI /AHD /TVI video converter can simultaneously transmit 1/2/4/8/16 CH composite video.

Feature is real-time, synchronous, lossless, high reliability, coaxial point to point transmission.

The play-and-plug design makes the installation more convenient and easier for our customer.







Feature

  • Ø Non-compression coding technology
  • Ø Automatically identify formats of input videos
  • Ø Support transmission of 1~16 channel AHD signal and controlling data simultaneously though coaxial cable
  • Ø DC 5V power supply
  • Ø Support 720p/25,720p/30,720p/50,720p/60, 1080p/25, 1080p/30 videos etc
  • Ø Through LED indicators to inform its functional mode
  • Ø Industrial wide range of operational temperature
  • Ø Plug and play, simple installation







Application



² City traffic monitoring system

² Public security, safe city monitoring system

² Highway security protection, charging system

² Building, campus monitoring net

² Industrial monitoring (airport, chemical industrial, steel, oil, railway, water conservancy, mine, etc)

² Military monitoring (storehouse, frontier defense, guard, nation defense, etc)

² electric power, oilfield, television program transmission system

² Gymnasium (live video, audio transmission)







AHD TO Fiber Converter System connection diagram



DC 5V 2A HD 1080p Video Converter 8-Ch HDCVI / HDTVI / AHD Video Converter









Technical Indexes

Fiber FC, Single Mode Single Fiber
Transmission Distance 0-120km (Optional)
Wavelength Transmitter: 1310nm(Tx)/1550nm(Rx)
Receiver: 1550nm(Tx)/1310nm(Rx)
Transmitter Input Level >500mVp-p
Receiver Output Level 1Vp-p
Self-adaption cable equilibrium 1080p: 75-5 coaxial cable, 300m
720p: 75-5 coaxial cable, 500m
Transmitter Input Return Loss >15dB
Input/Output Impedance 75Ω
Video Physical Interface BNC
Video Channel 1-Ch~4-Ch
Video bandwidth 50MHz
Sampling Bandwidth 10 bit
RS485 1-Ch Backward RS485 (Optional)
Indicators OPT, PWR, DATA, VIDEO
Power DC 5V2A or AC220V
Power Consumption ≤7W
Operation Humidity 10%~90%
Operation Temperature -40°C~75°C





Packaging & Shipping



1 All of our package are international standard package

2 We will deliver our products as soon as the order confirmed
