120M HDMI Extender Over Single Cat 6 UTP Cables HDMI Transmitter and Receiver IR hdmi extender
1. Product Introduction
The device includes a sender (with “sender” mark) and a receiver (with “receiver” mark) , extends HDMI, RS232 and IR signals to remote places. Up to 90 meter with normal 8 core cat5e/6/7 cable, reach 100 meters with high quality cables from top brands.
High bandwidth, no loss, no frame delay, plays real time HD video at remote places.
Widely used in computing and surveillance systems, big screen advertisement system, video wall, bank, stock market, education system etc.
|Signals||Input||Sender: HDMI,IR,RS232 (one way each)|
|Output||Receiver:HDMI,IR,RS232 (one way each)|
|Video Parameters||HDMI Version||HDMI1.4|
|HDMI Resolution||1080p/1080i/720p/720i/576p/576i/480p/480i Up to 4K×2K|
|Color Format||24bit /deep 30bit /deep 36bit|
|I/O TMDS Signals||0.5-1.5Vp-p(TTL)|
|I/O DDC Signals||5Vp-p(TTL)|
|IR||Connector||3.5mm Audio Jack|
|Signals||IR remote control signal|
|RS232||Connector||3.5mm audio jack|
|Humidity||0-95% (No condense)|
3. Product Feature
● Works over single network cable, save cost
● Support HDMI1.1, 1.2, 1.3, 1.4 protocols
● Support HDCP
● HDBase-T technology, 10G high bandwidth, no signal loss, no frame delay, high quality video, anti electromagnetic interference.
● Support 3D
● IR function for option
● RS232 function for option
4. Packing Instruction
When you open the packing, you will find:
3. 1pcs*HDMI cable
4. 1pair*RS232 to audio cable (optional)
5. 1pair* IR cable (optional)
6. 2pcs*DC5V/3A power adaptor
7. User manual with warranty card
1. Application map
1. Take out the HDMI cable in package, connect host`s HDMI port to HDMI IN port of sender. Take out the RS232 to audio cable (optional), connect host`s RS232 port to 232 port of sender, insert the optional IR receiver (one ring around 3.5mm plug) into IR-OUT port.
The product is low voltage device. Please try to keep away from the high voltage equipment, electricity cable etc that with high interference during installation and better use FTP cable and shield connector, also connect to ground if in tough condition.
6. LED Indicator
|LED||Color||LED Status||Device Status|
|Link||Green||ON||Receiver is comunicating with sender|
|OFF||No comunicating between sender & receiver|
|Video||Orange||ON||Normal HDCP video signals input|
|Flash||Normal non HDCP video signals input,|
|OFF||No video input or monitor has bad connection|
7. Warranty and after sale service
* Our promises:
It is not within this scope if user dismantles the equipment by themselves; If the damage is caused by un-proper use or by man-made reasons which is not quality problem, then it is not within the free repair service
