1Channel CVI TVI AHD Video to Fiber Optic Converter with RS485

China 1Channel  CVI TVI AHD Video to Fiber Optic Converter with RS485 supplier
1Channel  CVI TVI AHD Video to Fiber Optic Converter with RS485 supplier 1Channel  CVI TVI AHD Video to Fiber Optic Converter with RS485 supplier 1Channel  CVI TVI AHD Video to Fiber Optic Converter with RS485 supplier 1Channel  CVI TVI AHD Video to Fiber Optic Converter with RS485 supplier 1Channel  CVI TVI AHD Video to Fiber Optic Converter with RS485 supplier 1Channel  CVI TVI AHD Video to Fiber Optic Converter with RS485 supplier 1Channel  CVI TVI AHD Video to Fiber Optic Converter with RS485 supplier 1Channel  CVI TVI AHD Video to Fiber Optic Converter with RS485 supplier

Large Image :  1Channel CVI TVI AHD Video to Fiber Optic Converter with RS485

Product Details:

Place of Origin: China
Brand Name: Ho-Link
Certification: CE/ROHS/FCC/SGS
Model Number: H-CVI-T/RF

Payment & Shipping Terms:

Minimum Order Quantity: 50pcs
Price: Negotiable
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 1-3 working days after received your payment
Payment Terms: T/T, Western Union
Supply Ability: 3,000pcs per month
Contact Now
Detailed Product Description
Model Number: H-CVI-1V-T/RF Function: Video To Fiber Optical Modem
Optical Connector: FC/SC/ST Fiber Type: SMF
Wavelength: 1310nm, 1550nm Physical Interface: BNC
Warranty: 3 Years Certification: CE/FCC/RoHs Compliant



1Ch CVI Video to Fiber Optic Converter



Introduction:



Our CVI Video over Fiber Converters can simultaneously transmit 1-8 channels AHD over one multimode or single-mode optical fiber. Electronic and optical adjustments are never required. LED indicators are provided for instantly monitoring system status. Devices are available for either standalone or rack-mount installation, which is suitable for different working environment .



Its optical module and core circuit adopt the imported components that have high stability, and all optical & electrical interfaces conform to the international standards, which is applied to the different working environment. This optical transceiver with video status indication can monitor the normal operation of system.

1Channel  CVI TVI AHD Video to Fiber Optic Converter with RS485







Features:



1. Analog HD video 1080P (1920x1080) / 960P (1280 x 960) / 720P (1280 x 720) destegi, Desteklenen formatlar AHD / HD-TVI / HD-CVI

2. Automatic compatible PAL, NTSC and SECAM video system

3. 10-bit digital code and non-compression type video transmission .

4. Power supply and other parameter state indication, which can monitor the operation condition of system

5. Support no-damage regenerative trunk of video

6. Constant input optical power, and large dynamic range ,no Electrical or Optical Adjustments Required .

7. Special ASIC design .

8. It is plug-and-play and supports hot-swap, convenient for fixing without modulation.

9. Can be installed in 19 inch rack-mounted chassis(2U/4U).



PRODUCT APPLICATION SCOPE



1. Public Security Surveillance

2. Intelligent Transportation System

3. Connection of Sub-network for Surveillance Center

4. High Way & Toll Station Surveillance

5. High Quality Video Conference

6. Industrial Closed Circuit Television Surveillance

7. Coliseum using for TV-live ,audio transmission



Technical Specification:



Video parameters:



1-16Ch AHD Video over Fiber Converter for 720P, 1080P/4Ch 720P/960P/1080P HD-CVI/AHD/TVI Converter



Holink HDCVI Video Over Fiber Converter adopt the advanced uncompressed

HD composite video and high velocity digital optical transmission technologies which convert the HDCVI composite signals to optical signals to achieve long distance(as far as 80Km) transmission through fibers.


Ordering Information
Model Description(FC,SM,20KM)
H-H1VF-T/R 1ch HD-CVI/TVI/AHD video 720P
H-H1V1DF-T/R 1ch HD-CVI/TVI/AHD video 720P + 1ch Reverse RS485 Data
H-H2VF-T/R 2ch HD-CVI/TVI/AHD video 720P
H-H2V1DF-T/R 2ch HD-CVI/TVI/AHD video 720P + 1ch Reverse RS485 Data
H-H4VF-T/R 4ch HD-CVI/TVI/AHD video 720P
H-H4V1DF-T/R 4ch HD-CVI/TVI/AHD video 720P + 1ch Reverse RS485 Data
H-H8VF-T/R 8ch HD-CVI/TVI/AHD video 720P
H-H8V1DF-T/R 8ch HD-CVI/TVI/AHD video 720P + 1ch Reverse RS485 Data
H-H16VF-T/R 16ch HD-CVI/TVI/AHD video 720P
H-H16V1DF-T/R 16ch HD-CVI/TVI/AHD video 720P + 1ch Reverse RS485 Data
H-HD1VF-T/R 1ch HD-CVI/TVI/AHD video 1080P
H-HD1V1DF-T/R 1ch HD-CVI/TVI/AHD video 1080P + 1ch Reverse RS485 Data
H-HD2VF-T/R 2ch HD-CVI/TVI/AHD video 1080P
H-HD2V1DF-T/R 2ch HD-CVI/TVI/AHD video 1080P + 1ch Reverse RS485 Data
H-HD4VF-T/R 4ch HD-CVI/TVI/AHD video 1080P
H-HD4V1DF-T/R 4ch HD-CVI/TVI/AHD video 1080P + 1ch Reverse RS485 Data
H-HD8VF-T/R 8ch HD-CVI/TVI/AHD video 1080P
H-HD8V1DF-T/R 8ch HD-CVI/TVI/AHD video 1080P + 1ch Reverse RS485 Data
H-HD16VF-T/R 16ch HD-CVI/TVI/AHD video 1080P
H-HD16V1DF-T/R 16ch HD-CVI/TVI/AHD video 1080P + 1ch Reverse RS485 Data






1Channel  CVI TVI AHD Video to Fiber Optic Converter with RS485
