Ho-Link 720P/1080P HDCVI/TVI/AHD to Fiber Video Converter HD Video Transeiver support Dahua 720P/1080P CCTV Camera

China Ho-Link 720P/1080P HDCVI/TVI/AHD to Fiber Video Converter HD Video Transeiver support Dahua 720P/1080P CCTV Camera supplier
Ho-Link 720P/1080P HDCVI/TVI/AHD to Fiber Video Converter HD Video Transeiver support Dahua 720P/1080P CCTV Camera supplier Ho-Link 720P/1080P HDCVI/TVI/AHD to Fiber Video Converter HD Video Transeiver support Dahua 720P/1080P CCTV Camera supplier Ho-Link 720P/1080P HDCVI/TVI/AHD to Fiber Video Converter HD Video Transeiver support Dahua 720P/1080P CCTV Camera supplier Ho-Link 720P/1080P HDCVI/TVI/AHD to Fiber Video Converter HD Video Transeiver support Dahua 720P/1080P CCTV Camera supplier

Large Image :  Ho-Link 720P/1080P HDCVI/TVI/AHD to Fiber Video Converter HD Video Transeiver support Dahua 720P/1080P CCTV Camera

Product Details:

Place of Origin: China
Brand Name: Ho-Link
Certification: CE/ROHS/FCC/SGS
Model Number: H-CVI/TVI/AHD-T/RF

Payment & Shipping Terms:

Minimum Order Quantity: 5 Pair
Price: Negotiable
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 1-5 working days after received your payment
Payment Terms: T/T, Western Union
Supply Ability: 3,000pcs per month
Contact Now
Detailed Product Description
Function: Video To Fiber Optical Converter Optical Connector: FC/SC/ST
Power: DC5V 2A Operation Mode: Full Duplex / Half Duplex
Color: Black Warranty: 3 Years
Storage Humidity: 10%~90% RH Video Connector: BNC
Case Material: Aluminum

1Ch CVI/TVI/AHD Digital Video to Fiber Optic Converter



Introduction:

Ho-Link 720P/1080P HDCVI/TVI/AHD to Fiber Video Converter HD Video Transeiver support Dahua 720P/1080P CCTV Camera




This HDCVI TO Fiber video Converter can simultaneously transmit 8 channels HDCVI and 1CH reverse RS485 over one multimode or single-mode optical fiber. Electronic and optical adjustments are never required. LED indicators are provided for instantly monitoring system status. Devices are available for either standalone or rack-mount installation ,which is suitable for different working environment . Compatible with 1280H/25f, 1280H/30f, 1280H/50f, 1280H/60f. Lossless non-compression real time transmission.In addition,ethernet/telephone/audio/contact closure can be added when you need.It support Dahua and other brand CCTV CVI cameras.



Specifications:



Opitcal:



Wavelength 1310nm&1550nm
Output Power -8~3dBm
Optic fiber 50/125u multimode,62.5/125u multimode,9/125u single mode
Rx sensitivity -25dBm
Optical connector FC,ST,SC (optional)
Distance 0~550M (MM) / 0~20KM (SM)



Video:



Number of Channels 4
Input/output impedance BNC 75Ω (unbalance)
Standard video input/output voltage 1.0Vp-p
Video Bandwidth 45MHz
Sampling Bandwidth 10bit
Sampling Frequency 108MHz
Rise and Fall time <0.8ns
Optical Signal Intrinsic Jitter <0.2 UI
Differential Gain < ±1.5%
Differential Phase < ±1°
Connector BNC



Other



Power DC5V 2A
Power Consumption ≤6W
Temperature -40ºC ~75ºC
Humidity 10%~90% RH
Unit Weight 1.5KG(pair)
Dimension 175mm×154mm×30mm
Installation Wall mount
MTBF ≥ 100000Hours




HDTVI TO Fiber Converter System connection diagram:



Ho-Link 720P/1080P HDCVI/TVI/AHD to Fiber Video Converter HD Video Transeiver support Dahua 720P/1080P CCTV Camera

Ho-Link 720P/1080P HDCVI/TVI/AHD to Fiber Video Converter HD Video Transeiver support Dahua 720P/1080P CCTV Camera
About US:

Ho-Link 720P/1080P HDCVI/TVI/AHD to Fiber Video Converter HD Video Transeiver support Dahua 720P/1080P CCTV Camera

Holink Technology Co., LTD is an ISO 14000:2004 & ISO 9001:2008 certified manufacturer specialized in R&D, production, sales and services of Optical Transmission products. Relying on the rapid growth of Data Center and HPC, Holink has become a Top-100 maker and one of the earliest suppliers for optical products, including optical modules and HDMI/SDI video over fiber converter.
