1ch VGA To Fiber Converter+1 Channel Forward Audio +1 Channel Forward RS232 Data

China 1ch VGA To Fiber Converter+1 Channel Forward Audio +1 Channel Forward RS232 Data supplier
1ch VGA To Fiber Converter+1 Channel Forward Audio +1 Channel Forward RS232 Data supplier 1ch VGA To Fiber Converter+1 Channel Forward Audio +1 Channel Forward RS232 Data supplier 1ch VGA To Fiber Converter+1 Channel Forward Audio +1 Channel Forward RS232 Data supplier 1ch VGA To Fiber Converter+1 Channel Forward Audio +1 Channel Forward RS232 Data supplier 1ch VGA To Fiber Converter+1 Channel Forward Audio +1 Channel Forward RS232 Data supplier

Large Image :  1ch VGA To Fiber Converter+1 Channel Forward Audio +1 Channel Forward RS232 Data

Product Details:

Place of Origin: China
Brand Name: Ho-Link/OEM
Certification: CE/FCC/ROHS
Model Number: H-VGA-1V1D1A-T/RL

Payment & Shipping Terms:

Minimum Order Quantity: 1pair
Price: Negotiable
Packaging Details: International Standard Package
Delivery Time: 3 working days after received your payment
Payment Terms: T/T, Western Union
Supply Ability: 3,000pairs per month
Contact Now
Detailed Product Description
Product Name: VGA Over Fiber Converter Transmission Wavelength: 1310nm/1550nm
Type: Single-mode Transmission Distance: 20KM
Digital Bits Wide: 10 Bit Signal Level: RS232 Standard Level

1ch VGA Optical transmitter and receiver+1 Channel Forward Audio +1 Channel Forward RS232 Data, 10km on single mode







Overview:





   Optical Multiplexer is popularly with telecommunication operator and suitable in business for communication operator, government and kinds of entities. It is one of the most transmission equipment in point-point fiber optic network. Typical optical multiplexers are Video & Data & Audio Multiplexers, PDH Multiplexer.Holink optical multiplexers are highly manageable, accompanied by a network management system for configuration, service, performance, security, and fault management that enable cost-effective and efficient transport.



   digitally transmits high-resolution VGA/RGB (up to WXGA) and stereo audio over one fiber, single-mode or multimode, single-core, 1310 nm wavelength. Ideal for point-to-point, point-to-multipoint and drop-and-repeat applications



1ch VGA To Fiber Converter+1 Channel Forward Audio +1 Channel Forward RS232 Data












Main features:



  1. CRAFT: uncompressed technology
  2. VIDEO SPEC: 1080P 30 Hz
  3. Transmisson Distance:20km
  4. Fiber Type: Single-mode Simplex
  5. Range from 19.4Mb/s to 1.485Gb/s
  6. SMPTE 292M (1.485Gb/s) clock recovery
  7. Support all SMPTE 295M standard, 143Mb/s - 360Mb/s
  8. LED Status Indication to monitor the working conditions and critical parameters
  9. Optional network management system
  10. Support SFP transceiver hot-plugged
  11. Support stand-alone, 1U rack mount and 4U rack mount













Specifications:



Interface
VGA IN VGA signal input
VGA OUT VGA signal output
AUDIO IN Audio signal input
AUDIO OUT Audio signal output
OPT OUT Fiber output
OPT IN Fiber input
UART Serial telecommunication port
DC 5V power



Indicator Light VGA Transmitter VGA Receiver
VIDEO On With video signal
Off Without video signal
LOCK On Fixed video signal
Off Without fixed video signal
RUN On Device works smoothly
Off Device not works smoothly
POWER On Power on
Off Power off








Video
Type RGB with stand-alone and sync H, V
Input level 1Vp-p
Output level 1Vp-p
Bandwidth (-3 dB) 1.65G
Digital bits wide 10bit
Resolution 640X480 @ 70fps
1920X1080 @ 25fps
1024X768 @ 60fps
800X600 @ 70fps
1600X1200 @ 30fps
1280X1024 @ 30fps
720X576 @ 50fpsv
720X480 @ 60fps
1440x900 @ 30fps
1280X720 @ 30fps
1680x1050 @ 30fps
1400 x1050 @ 30fps
1360x768 @ 30fps
Audio
No. 1
Input/ output level 5Vp-p,unequilibrium
Connector Standard 3.5 mm stereo headphone jack
RS232 indication
Input/output interface 9-hole standard RS232 socket
Signal rate ≥115200bps
Signal level RS232 standard level
Optics
Type single-mode
Output optical power -5 ~ -10dBm
Receiver sensitivity 18dBm
Wavelength 1310/1550nm
Connector FC/PC (SC/PC optional)
Max. Link loss 12dB (bigger options)
Connector FC/PC (SC or ST optional)
Power and environmental indicator
Stand-alone power 5W
Insertion power 5W
Power adapter 220VAC to 12VDC/1A
Operating temperature -40°C to +70°C
Relative humidity < 95% (no condensation)











Application Diagram:



1,Connect VGA input signal to VGA_IN port by VGA cable

2,Connect VGA output signal to VGA_OUT port by VGA cable

3,Connect audio input signal to AUDIO IN

4,Connect audio output signal to AUDIO OUT

5,Connect serial port to UART

5,Connect LCfiber to OPT IN and OPT OUT

6,Power on







Shipping:

  1. Packaging : bags&caron box
  2. Shipping: International Express: Fedex, DHL, UPS, TNT and EMS.If you have another preferred carrier, please notify us in advance.
  3. FedEx Overnight: It will take 1-3 business days (weekends and holidays excepted) for delivery.
  4. DHL: It will take 2-4 business days (weekends and holidays excepted) for delivery. For Spain, Italy, Brazil and some other countries, items will take longer time to arrive due to customs clearance period.
  5. Orders usually shipped out within 2 working days after receiving your payment.

     Part 2 Standard Package

     VGA transmitter 1 pcs

     VGA receiver 1 pcs

     Power Supply Unit 5V/2A 2 pcs

     User Guide 1 pcs
