Home ProductsXLR Balanced Audio to Fiber Converter

2 Channel Forward XLR Balanced Audio to Fiber Converter,broadcasts quality audio signals up to 12.5 miles of single-mode

Certification
Good quality HD SDI Video to Fiber Converter for sales
Good quality HD SDI Video to Fiber Converter for sales
Our main concern before ordering products was the longevity and quality. product works good. We will consider more of your products in my projects.

—— Ilan

works great easy to use, I recommend seller

—— paul rusnock

inexpensive product, fast delivery, and does its job.Very good service fast shipping.Thank You

—— Cal T.

I'm Online Chat Now

2 Channel Forward XLR Balanced Audio to Fiber Converter,broadcasts quality audio signals up to 12.5 miles of single-mode

China 2 Channel Forward XLR Balanced Audio to Fiber Converter,broadcasts quality audio signals up to 12.5 miles of single-mode supplier
2 Channel Forward XLR Balanced Audio to Fiber Converter,broadcasts quality audio signals up to 12.5 miles of single-mode supplier 2 Channel Forward XLR Balanced Audio to Fiber Converter,broadcasts quality audio signals up to 12.5 miles of single-mode supplier 2 Channel Forward XLR Balanced Audio to Fiber Converter,broadcasts quality audio signals up to 12.5 miles of single-mode supplier 2 Channel Forward XLR Balanced Audio to Fiber Converter,broadcasts quality audio signals up to 12.5 miles of single-mode supplier 2 Channel Forward XLR Balanced Audio to Fiber Converter,broadcasts quality audio signals up to 12.5 miles of single-mode supplier

Large Image :  2 Channel Forward XLR Balanced Audio to Fiber Converter,broadcasts quality audio signals up to 12.5 miles of single-mode

Product Details:

Place of Origin: China
Brand Name: Ho-Link
Certification: CE/ROHS/FCC/SGS
Model Number: HL-XLR-S2A↑-T/RF

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: Negotiable
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 1-3 working days after received your payment
Payment Terms: T/T, Western Union
Supply Ability: 3,000pcs per month
Contact Now
Detailed Product Description
Wavelength: 1310nm&1470nm~1610nm Number Of Channels: 2 Channels
Optical Connector: FC/ST/SC/LC (optional) Rx Sensitivity: -24dBm
Transmission Distance: 0~20KM/40KM/60KM/80/100KM (SM) Relative Humidity: 0% ~ 95% (non-condensing)
Operating Temperature: -20°C ~ +75°C Storage Temperature: -40°C ~ +85°C
MTBF: >100,000 Hours



2 Channel Forward XLR Balanced Audio to Fiber Converter






Product Description


Introduction


The balanced audio sends balanced line level XLR broadcast quality audio signal up 12.5 miles on single mode fiber.The system consists of a transmitter and receiver that support 16-bit digitally encoded broadcast audio for use on single mode optical fiber.

2 Channel Forward XLR Balanced Audio to Fiber Converter,broadcasts quality audio signals up to 12.5 miles of single-mode

Feature


These fiber optic transmitter and fiber optic receiver are typically used in applications for Rental, Staging, Theater, stand-alone or rack-mount installations.Plug and Play design ensures adjustment-free installation and operation, and optical adjustments are never required. LED indicators are provided to instantly monitor the system operating status.


Connection Diagram:
2 Channel Forward XLR Balanced Audio to Fiber Converter,broadcasts quality audio signals up to 12.5 miles of single-mode








Technical Specification


Parameter Specifications
Optical Wavelength 1310nm&1470nm~1610nm
Output Power -1~ -8dBm
Optic Fiber

50/125u multimode,62.5/125u multimode,9/125u single mode

Rx Sensitivity -24dBm
Optical Connector FC/ST/SC/LC (optional)
Distance 0~20KM/40KM/60KM/80/100KM (SM)

Balanced Audio



Number of Channels 2
Input Connector XLR (female)
Output Connector XLR (male)
Input / Output Impedance 10K Ohm
Input Capacitance LINE Inputs 10 pF
Max Input/output Voltage 1.228Vp-p (+4dBu)
Frequency Response 10 Hz~24kHz @±3dB
Sample Rates From 48kHz
SNR > 80dB
Electrical & Mechanical Input Power Requirements DC 12V@1A
Power Adapter AC 100V~240V
Power Consumption < 5W
Dimensions 167mm × 113mm × 44mm
Weight 1.35kg(include Transmitter & Receiver )

Environmental

Operating Temperature

-20°C ~ +75°C

Storage Temperature

-40°C ~ +85°C

Relative Humidity 0% ~ 95% (non-condensing)
MTBF

>100,000 hours

Packaging & Shipping



1 All of our package are international standard package
2 We will deliver our products as soon as the order confirmed

Shipment
2 Channel Forward XLR Balanced Audio to Fiber Converter,broadcasts quality audio signals up to 12.5 miles of single-mode
